Product Range
Power : 1 to 1300 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 7 DI, 3 Relay O/P, 4 AI, 3 AO

Features
- Open-loop (volts/frequency) control
- Sensorless Vector Control
- Closed-loop vector control
- Pre-programmed application macros
- Open standard fieldbus communications
- Programming identical to DC 590+ DC drive
- Class B EMC filters
- Energy Saving (fast return on investment in pump and fan applications)
- Improved HVAC control

Product Range
Power : 1.5 to 150 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 6 DI, 3 Relay O/P, 2 AI, 2 AO
Features
- Sensorless Vector Control
- Built in EMC Filter
- Built in brake chopper up to 11 KW
- Plugin type fieldbus modules(optional)
- The interactive Assistant Control Panel(optional)

Product Range
Power : 1 to 200 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 6 DI, 3 DI/DO, 1 Relay O/P, 2 AI, 2 AO, Motor thermistor input
Features
- Speed control torque control as well as motion control variant
- Asynchronous and synchronous motor compatibility
- Drive to drive link as Standard
- Supports PROFIBUS,CAN open, Device Net and Ethernet communication
- Intigrated Safe Torque- Off (STO) function
- Intigrated braking chopper
- Modular Design
- Memory unit for easy drive management

Product Range
Power : 0.33 to 200 Hp
Voltage : 1 Ø 230VAC,3 Ø 380 to 480 VAC
Programmable Control Connections : 4 DI, 1 DI/DO, 1 Relay O/P, 2 AI, 1 AO
Features
- Automatic no-spin autotune for rapid performance optimization
- 8 preset speeds available for greater application flexibility
- Keypad access to all parameters – basic and advanced menus
- Open loop vector control. Speed or Torque control
- Switching frequency from 3kHz up to 18kHz - quiet motor operation
- Linear and S type acceleration and deceleration ramps
- Modbus RTU RS485 via RJ45 connector as standard
- DC injection braking as standard
- Dynamic braking transistor as standard
- Energy savings with dynamic motor flux V/Hz
- Fan and pump energy optimization with quadratic motor flux V/Hz
- Advanced standard software features, such as timers,thresholds, maths blocks, logic operators, PID controller and kW/h meter

Product Range
Power : 0.5 to 200 Hp
Voltage : 1 Ø 230VAC,3 Ø 380 to 480 VAC
Programmable Control Connections : 5 DI, 1 DI/DO, 1 Relay O/P, 3 AI, 2 AO
Features
- Open loop V/Hz AC drive
- Open loop Vector AC drive
- Open loop Rotor Flux Control (RFC)
- Closed loop Vector AC drive
- Servo for synchronous permanent magnet motors / brushless servo motors
- Widest range of system integration features
- Backup power supply for continuous operation
- On Board PLC (Optional)
- Easy parameter backup and copy
- Integrated brake resistors
- Flexible Mounting

Product Range
Power : 1 to 1000 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 8 DI, 1 Pulse Input,1 Pulse Output, 1 Relay O/P, 3 AI, 2 AO
Features
- Closed or open loop vector control, torque production, and position control capability
- High Slip Braking reduces installation cost and the need for dynamic braking resistors
- Communication options for all major industrial networks provides high speed control and monitoring, reducing installation cost
- Auxiliary Control Power Unit maximizes production time and efficiency by maintaining network communication while main power is removed
- Embedded function blocks, programmable with DriveWorks EZ, provide additional application flexibility and the opportunity to eliminate separate controllers
- USB Copy Unit and Keypad configuration storage provide speed and convenience for duplicate configuration of multiple drives
- Removable terminal board with configuration storage provides convenience of configuration backup
- Integrated DC Reactor (standard on 30HP and larger) for input harmonic reduction
- Kinetic Energy Braking allows drive to remain in control during momentary power losses

Product Range
Power : 0.5 to 25 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 7 DI, 2 DO,1 Relay O/P, 2 AI, 2 AO
Features
- V/f Control,Open Loop Current Vector Control
- Exceptional Performance Life – 10 years(Assumes operation condition at 40°C, 80% Load & 24 Hours Operation)
- Exceptional low speed/high torque control
- Maintenance Monitors specifying used percentage life for drive Components. (IGBT, DC Bus Capacitors, & Fan)
- Faster Replacement of drive with parameters backedup in Terminal Block.
- Last Fault Trace & Last Ten Fault History for easyTroubleshooting.
- Verify Menu listing all changed parameters from default setting enables easy understanding of application.
- Backup parameters usingUSB copy Unit / PC DriveWizard Software.
- Instant Setup of New drives using stored Backup

Product Range
Power : 1 to 20 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 7 DI, 2 DO,1 Pulse Input, 1 Pulse Output, 1 Relay O/P, 2 AI, 1 AO
Features
- High starting torque and dramatically improved speed stability with advanced sensorless vector control
- Simplified auto-tuning procedure
- Easy setup and operation via standard integral keypad, optional enhanced keypad or via PC software
- Dynamic braking transistor in all models
- Built in EasySequence (EzSQ) PLC-like functionality
- Simple position control capability
- Capable of driving permanent magnet as well as standard induction motors
- Dual rated for CT/VT applications
- New and more effective trip avoidance functions, safe-stop function

Product Range
Power : 1 to 75 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 8 DI, 5 DO, 1 Relay O/P, 3 AI, 3 AO
Features
- 50 Degree Ambient Temperature Design
- High starting Torque, Powerful Drive and easy setting
- Programming [EzSQ: Easy Sequence] function
- Built in EMC filters & Brake Circuit
- Position control Function
- Ease of Maintenance
- In Built some function of PLC with PID Controls
- RS-485,RS-422.
- Controlled deceleration and stop on power loss

Product Range
Power : 1 to 120 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 7 DI, 4 DO, 2 AI, 2 AO
Features
- Sensor less vector control, V/F control
- Encoder feedback, Resolver Feedback
- Inbuilt CAN Open For drive to drive and HMI data transfer.
- Freely connectable function block programming.
- Frequency input and output function
- 180% overload capacity for 60s
- Connection to common fieldbus systems (Optional)

Product Range
Power : 1 to 120 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : As per Optional Card
Features
- Sensor less vector control, V/F control
- Integrated RFI filter
- PID Controller
- Freely programmable inputs/outputs
- Freely connectable function block programming.
- Integrated brake transistor1
- Connection to common fieldbus systems (Optional)

Product Range
Power : 1 to 60 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 7 DI, 4 DO, 2 AI, 2 AO
Features
- Communication: CANopen on board,EtherCAT,EtherNet/IP,PROFIBUS,PROFINET(Optional)
- Suitable for drive applications with or without speed feedback
- Integrated positioning control
- Up to 15 selectable positioning points included each of the corresponding travel profiles
- Integrated brake management
- "VFC eco" energy-saving function
- STO safety function

Product Range
Power : 1 to 60 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 4 DI, 1 DO, 1 AI, 1 AO
Features
- Communication: CANopen on board,EtherCAT,EtherNet/IP,PROFIBUS,PROFINET(Optional)
- Suitable for drive applications with or without speed feedback
- Integrated positioning control
- Up to 15 selectable positioning points included each of the corresponding travel profiles
- Integrated brake management
- "VFC eco" energy-saving function
- STO safety function

Product Range
Power : 0.5 to 4 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 4 DI, 1 DO, 1 AI
Features
- Communication: CANopen (Optional)
- Quick and easy commissioning
- Integrated motor overload protection

Product Range
Power : 1 to 25 Hp
Voltage : 3 Ø 380 to 480 VAC
Programmable Control Connections : 3 DI, 1 DO, 1 Relay O/P, 2 AI, 1 AO
Features
- Sensor less vector control, V/F control
- PID Controller
- Connection to common fieldbus systems (Optional)
- Expansion of inputs and outputs with additional IO modules(Optional)
